X-tone X MIX8 Dsp
SOBRE EL PRODUCTO
the X-tone MIX8 Dsp is an 8-channel analog mixer.
Compact mixer, you can take it anywhere with you, whether you are a musician or a band, by connecting your favorite equipment:
- Microphones, instruments, keyboards, guitars, smartphone.
In addition, thanks to its integrated DSP, the mixer includes 16 effects, which will add to your tracks:
- Reverb, delay, echo, chorus, flanger, phaser...
CARACTERÍSTICAS
General Specifications
- Input channels : Mono(MIC/line):4
Stéreo(Line):2
- Output channels: Main L/R OUt:1
Phones 1
- Bus Stéreo:1
Input channel functio:
MIC/LINE GAIN,-14 + 40db
2 band EQ,80hz/12khz
+48v, phantom power, led
Impedance Switch
Peak LED
LEVEL METER 2x6 point LED meter
DSP effect 24 BIt sigma-delta, 256-times oversampling, 48khz sampling rate
MAX output level 3 Vrms
Frequency response: +0.5db, 20-20000hz
Dynamic Range 102db
THD+N 1khz <0.03%
Stereo crosstalk 92db
Power requirements DC5V 1a
Power consumption MAX5w
Dimensions 225mmx66mmx165mm
Net weight 1.3kg
Ref. Euroguitar : 91756
- Input channels : Mono(MIC/line):4
Stéreo(Line):2
- Output channels: Main L/R OUt:1
Phones 1
- Bus Stéreo:1
Input channel functio:
MIC/LINE GAIN,-14 + 40db
2 band EQ,80hz/12khz
+48v, phantom power, led
Impedance Switch
Peak LED
LEVEL METER 2x6 point LED meter
DSP effect 24 BIt sigma-delta, 256-times oversampling, 48khz sampling rate
MAX output level 3 Vrms
Frequency response: +0.5db, 20-20000hz
Dynamic Range 102db
THD+N 1khz <0.03%
Stereo crosstalk 92db
Power requirements DC5V 1a
Power consumption MAX5w
Dimensions 225mmx66mmx165mm
Net weight 1.3kg
Ref. Euroguitar : 91756
