Akg C104
The AKG C104 is a large-diaphragm cardioid condenser microphone designed to deliver premium audio quality with immediate ease of use. Its high-precision cardioid capsule and transformerless, optimized FET circuitry ensure a pure, detailed, and flattering sound, whether for vocals or a wide range of sources in the studio or for content creation.
Thanks to its very wide dynamic range and low noise floor, it captures everything from powerful electric guitars to very soft vocals (whispers) with clarity and definition. It also handles high SPL levels without perceptible distortion, making it versatile for a wide variety of uses: recording, podcasting, streaming, video conferencing/gaming, or broadcasting.
In terms of design, the AKG C104 reflects a commitment to sustainability: a body made from 100% recycled PIR metal, accessories and packaging optimized to reduce environmental impact, and fully recyclable packaging.
Type: Electret condenser
Diaphragm: 22 mm
Directional Pattern: Cardioid
Audio Performance
Frequency Response: 20 Hz – 20 kHz
Sensitivity: 13.5 mV/Pa (-37.5 dBV)
Self-Signal: 14 dB(A) SPL
Signal-to-Noise Ratio: 80 dB (re 1 Pa)
Maximum SPL (0.5% THD): 143 dB SPL
Electrical Characteristics
Impedance: ? 200 ohms
Recommended Load Impedance: ? 1000 ohms
Phantom Power: 48 V ±4 V (IEC 61938)
Current: ? 5 mA
Connectors: 3-pin XLR (pin 2 hot)
Dimensions & Weight
Length: 158 mm
Width: 47 mm
Height: 35 mm
Net Weight: 0.83 kg
Recommended Uses
Music Recording
Podcasts & Vlogs
Streaming / Online Conferencing / Gaming
Broadcasting
Box Contents
C104 Microphone
H81 Stand Mount
Quick Start Guide
Ref. Euroguitar : 120938
