Hk audio ELEMENTS MK2 110 Sub A
The HK AUDIO ELEMENTS MK2 110 Sub A is a compact active subwoofer designed for the ELEMENTS MK2 modular sound system. It is particularly well-suited for corporate events, conferences, vocal applications, and high-quality background music.
Equipped with a 10" driver featuring a 2.5" voice coil, it delivers powerful low-midrange response and ensures excellent speech intelligibility. Its compact design allows for both vertical and horizontal placement, depending on installation constraints.
Its Class D bi-amplified system delivers 900 W RMS and up to 1,800 W peak power. The built-in DSP automatically manages the ELEMENTS MK2 system and offers several presets tailored to different applications: Flat, Contour, Voice, and Remote.
The ELEMENTS MK2 110 Sub A also features the HK Audio DSP CONTROL platform, Ethernet network connectivity with Milan AVB audio transmission, and a DSP output for driving additional active speakers—for example, for delay lines or complementary systems.
Thanks to its two E-Connect MK2 outputs, it can power and connect ELEMENTS MK2 column speakers. Its bass-reflex design, rugged hybrid enclosure, and corrosion-resistant steel grille are suited for intensive professional use.
Enclosure type: Bass-reflex
Woofer: 1 x 10" with 2.5" voice coil
Max. SPL Peak: 123 dB
Crossover frequency: 175 Hz
Frequency response (-6 dB): 52 Hz – crossover frequency
Frequency response (-10 dB): 49 Hz – crossover frequency
Preamp type: DSP preamp
Amplification type: Class D bi-amplified
RMS output power: 900 W
Peak output power: 1800 W
Power consumption: 1.0 A / 100–240 V nominal per EN 62368-1
Maximum input level: 20 dBu
Speaker protection: RMS/Peak limiter
Sampling rate: 48 kHz
DSP functions: 10-band parametric EQ with variable filter characteristics, high-pass filter, low-pass filter, polarity, DSP-Out delay (up to 50 ms), limiter, mute
Remote control software: HK Audio DSP CONTROL
Presets: Flat, Contour, Voice, Remote
Digital audio transmission: Milan AVB
Analog input: 1 x balanced XLR
Analog output: 1 x balanced XLR
DSP output: 1 x balanced XLR
Satellite outputs: 2 x E-Connect MK2
Network input: 1 x EtherCON RJ45
Network output: 1 x EtherCON RJ45
Mains power: 1 x IEC connector
Enclosure material: Hybrid construction
Enclosure finish: Water-based acrylic paint
Color: Jet Black (RAL 9005)
Handles: 2 x Gripshell with crossbar
Grille: Steel grille with anti-corrosion treatment and acoustic foam
Dimensions (W x H x D): 32.8 x 48.6 x 67.3 cm
Weight: 28.5 kg
Ref. Euroguitar : 126017
